Images were taken with a self-modified Full Spectrum Canon 6D full frame camera. I have a review of the Canon 6D model posted HERE.
Imaging scope used was a 12" Astro-Tech RC telescope using a new Orion HDX110 equatorial GoTo mount. For lifting the heavy mount (55 lbs.) onto the pier and the telescope (50 lbs.) onto the mount, I use a small hydraulic lift table that I take with me. The tripod/pier weighs 65 lbs. and I used a large plastic container with wheels to move it to where I set up. A Youtube video of my Orion HDX110 field setup can be seen HERE.
The EQMOD ASCOM driver was used to drive the HDX110 mount directly via a USB2EQ5 Interface Cable.
Equipment used:
The Orion HDX110 mount was polar aligned at first using the mount's polar align scope and then later tweaked using the drift align function of PHDGuiding 2.
During this New Moon period we had 2 clear (useable) nights out of a 7 night stay.
M51 Whirlpool Galaxy - 050816:
14 six-minute exposures at ISO 1600 captured with AT12RC at prime using Full Spectrum modified 6D were combined using DeepSkyStacker and reduced in size for display (1200X768). 18 dark frames and Master Flat & Bias were used for calibration.
M101 Pinwheel Galaxy - 050916:
15 six-minute exposures at ISO 1600 captured with AT12RC at prime using Full Spectrum modified 6D were combined using DeepSkyStacker and reduced in size for display (1200X768). 17 dark frames and Master Flat & Bias were used for calibration.
M104 Sombrero Galaxy - 050916:
15 six-minute exposures at ISO 1600 captured with AT12RC at prime using Full Spectrum modified 6D were combined using DeepSkyStacker and reduced in size for display (1200X766). 18 dark frames and Master Flat & Bias were used for calibration.
Same as above bot rotated and cropped:
Mercury Transit - 050916:
I forgot to bring my adapters for connecting my Canon DSLR camera directly to the telescope. So instead, I held my T5i camera with kit lens up to a borrowed eyepiece from a friend. The image below was taken at 11:03 am with these camera settings: ISO 100, f5.6, 1/250 second exposure at 55mm. The image was shot through my Short Tube 80 autoguide scope with a 60mm Coronado H-alpha solar filter.
May 7, 2016 - Work Bee - Youtube Video:
A work session was held at Cherry Springs Dark Sky Park on May 7, 2016 to plant trees donated by the Cherry Springs Dark Sky Fund. The trees are for blocking vehicle headlights from the public program side of Cherry Springs shining onto the astronomy field. Thanks to all the volunteers that were able to help out and thanks to Maxine Harrison for the excellent lunch and refreshments.
